2008 Triumph Bonneville T120
Make Model Year Engine Four stroke, parallel twin cylinder, DOHC, 4 valves per cylinder Capacity Induction Ignition Starting Max Power Max Torque Transmission Front Suspension Rear Suspension Front Brakes Rear Brakes Front Tyre Rear Tyre Dry Weight Wet Weight Fuel Capacity
Triumph Bonneville T100 2007 - 08 865 cc / 52.8 cu in Bore x Stroke 90 x 68 mm Cooling System Air-cooled Compression Ratio 9.2:1 Lubrication Wet sump Engine Oil Synthetic, 15W/50 Twin carburetors, electrically heated Digital Electric 50 kW / 67 hp @ 7500 rpm 69 Nm / 7.04 kgf-m / 51 ft-lb @ 5800 rpm Clutch Wet, multi plate 5 Speed Final Drive Chain, X-ring Frame Tubular steel cradle, swing arm: twin-sided, tubular steel 41mm Kayaba telescopic forks Kayaba chrome spring twin shocks with adjustable preload Single 310 mm disc, 2 piston calipers Single 255 mm disc, 2 piston calipers Wheels Front 36 Spokes, 19 x 2.5 in Wheels Rear 36 Spokes, 17 x 3.5 in 100/90 19 130/80 17 Rake 28� Trail 110 mm / 4.3 in Dimensions Length 2250 mm / 88.6 in
Width 860 mm / 33.8 in
Height 1105 mm / 43.5 in Wheelbase 1493 mm / 58.8 in Seat Height 775 mm / 30.5 in 205 kg / 451 lbs 226 kg / 499 lbs 16.6 Litres / 4.4 US gal / 3.7 Imp gal
A blast from the past that rocks today.
Adding subtle touches to the uncluttered Bonneville form, the T100 wears a little extra to mark its connection with the classic �deluxe� speedster of the sixties. The tank with hand painted coach lines and chromed engine covers are just a couple of features that add to the T100�s overall elegant presence. It gracefully tackles traffic and finds jaunts to the countryside irresistible, while remaining the very epitome of sophistication and style.
The Modern Classics Range - Bikes that reflect the original freedom and fun of biking. Beautifully engineered and meticulously detailed - they�re the real thing. Powered by authentic air-cooled parallel twins, their performance, handling, brakes and fuel injection are bang up to date. And the look? - that�s genuinely classic.
FEATURES:
Engine
The T100�s full-blooded and responsive 865cc parallel twin-cylinder engine delivers throaty acceleration, amplified by the mellow backbeat from its twin peashooter exhaust pipes. Maximum power of 67bhp arrives at 7500rpm, with peak torque of 51ft.lbf delivered at 5800rpm.
Fueling
Twin carburetors with throttle position sensor and electric carburetor heaters
Exhaust System
A pair of chromed stainless peashooter-style pipes handle the exhaust gases and enhance the traditional appearance of the bike.
Fuel Tank
The T100 features a classically styled dual colored tank, with hand painted coach lines, rubber knee pads and �60�s inspired chromed tank badges.
Brakes
The braking set-up of single front 310mm disc and 255mm rear, both worked on by powerful twin-piston calipers offers sensitivity, control and ample stopping power.
Chassis
The chassis � a tubular steel frame, 41mm telescopic forks and chromed twin rear shocks � offers secure road-holding, effortless steering and easy-going manners, just as you would expect of a bike derived from Bonneville hereditary. It�s topped by a generous seat, with plenty of room for two and an elegantly embossed Triumph logo.
Source: https://www.motorcyclespecs.co.za/model/triu/triumph_bonneville%20T100%2008.htm
